Fuji Electric RC Blowers & Pumps

Fuji Electric offers a wide range of Regenerative Blowers, High Pressure Blowers, Turbo Style Blowers, Coolant Pumps, Air Knife Systems and Vacuum Systems.

VFC Series Ring Compressors

The VFC Series are single-stage ring compressors with a maximum pressure of 139 in. H2O, a maximum vacuum of 110 in. H2O and a maximum capacity of 570 SCFM. Motors are direct drive from 1/10 to 20 HP. Voltages are available in 115 single phase, 230 single phase, 230/460 3-phase dependent upon motor size. All units are provided with threaded flanges.

VDF Series Ring Compressors

The VFD Series are single or two stage ring compressors with a maximum pressure of 237 in. H2O, a maximum vacuum of 156 in. H2O, and a maximum capacity of 812 SCFM. Motors are direct drive from .87 to 30 HP. Voltages are available in 115 single phase, 230 single phase, 230/460 3-phase dependent upon motor size. All units are provided with threaded flanges.

VFT Series Turbo Blowers

VKN - Self Priming Coolant Pumps

The VKN pumps have mechanical seals and are intended for the circulation of coolant and spraying of cutting oil in all types of machines except grinders. They feature a ceramic stationary seal face, a carbon graphite rotating seal face, Buna-N elastomers, and steel springs.

 VKP - Submersible Pumps

The immersion-style pumps with no mechanical seals provide circulation of coolant and spraying of cutting oil in all types of machines including grinders. They are intended for use with non-flammable fluids that are compatible with pump construction materials. The max. recommended viscosity is 1200 at 50Hz and 600 at 60Hz. The max. liquid temp. is 104°F.

VKR & VKP - Submersible Pumps

The high pressure pumps can provide up to 30% greater delivery pressure than the standard models. These pumps are designed to not have mechanical seals and provide circulation of coolant and spraying of cutting oil in all types of machines, including grinders. The max. recommended viscosity is 1200 at 50Hz and 600 at 60Hz. The max. liquid temperature is 104°F.

Accessories

Fuji Electric provides a wide variety of Blower accessories to complete your installation. Accessories include Pressure and Vacuum Relief Valves, Inlet and Vacuum Filters, Aspirators, Silencers and Vacuum Boosters.

Do you have a Fuji application?
